220 kV Power Transformer (PWR-039)Item PWR-039

220 kV Power Transformer

220千伏电力变压器

220 kV oil-immersed power-transformer range with two- or three-winding and on-load or off-circuit voltage-regulating configurations.

Project-specific configurationOnly sourced values are shown. GoEastAI confirms remaining parameters during technical review.
Request this equipment Ask a question

Manufacturing source: Baoding Zhongyi Electric Group Co., Ltd. — Supplier Profile

Equipment overview

Built around the confirmed duty

The 2026 manual documents four 220 kV power-transformer arrangements: double-winding off-circuit regulating, double-winding on-load regulating, three-winding off-circuit regulating and three-winding on-load regulating. Capacity and voltage combinations vary by the selected handbook table.

Working principle

Electromagnetic induction transfers power between the selected two- or three-winding system. The tap-changing arrangement regulates the output ratio either under load or while de-energized.

Power and transmission equipment selection is based on power or torque, speed, load profile, service factor, electrical supply, mounting, environment, efficiency and integration requirements.

Core features

  • Four documented winding and voltage-regulation arrangements
  • Capacity and ratio selected from the confirmed system duty
  • Oil-immersed transmission-class construction
Technical parameters

Reference specification checklist

Use these common industrial selection fields to prepare the inquiry. They are not a manufacturer datasheet or guaranteed performance values.

Source-supported dataValues currently supported by supplied material
ParameterConfirmed valueBasis
Voltage class220 kV2026 product manual, page 13
Winding configurationsTwo-winding or three-winding2026 product manual, page 13
Voltage regulationOn-load or off-circuit2026 product manual, page 13
Documented capacity span31.5–300 MVARange across handbook tables; configuration dependent
Planning reference

Parameters to confirm before quotation

Final values remain subject to supplier technical review.

Swipe horizontally to view all parameter columns.

ParameterReference settingTypical unitSelection note
Rated power / torqueContinuous and peak dutykW / N·mInclude starting and overload requirement
Input / output speedProcess requirementr/minOperating range, ratio and direction as applicable
Electrical supplyDestination-specificV / Hz / phaseVoltage tolerance, starting and harmonic limits
Load profile and service factorRequired—Hours, starts, shock, inertia and reversing duty
Protection and environmentSite design basisIP / °CAmbient, altitude, dust, moisture and hazardous area
Mounting and shaft interfaceConfirm drawingmmFrame, flange, foot, shaft, key and coupling details
Efficiency / insulationProject targetIE class / classEfficiency, insulation, cooling and temperature rise
Control and monitoringLocal / VFD / plant integrated—Sensors, protection, communication and condition monitoring
